ÖLFLEX 100 I

Overview

LAPP KABEL STUTTGART ÖLFLEX 100I 3G 1.5 1100 volts IS 694 Standard lengths available in 100m,300m, 500m.

Product Details

• Core identification code : As per IS:694:2010
• Conductor stranding : Class V - According to IS 8130/IEC 60228
• Specific insulation resistance : 10 MΩ/km
• Minimum bending radius : occasional flexing: 15 × cable diameter
• Minimum bending radius : fixed installation: 4 × cable diameter
• Rated Voltage : 1100 V
• Test voltage : 3000 V
• Protective conductor : G = with protective conductor GN/YE
• Protective conductor : X = without protective conductor
• Range of temperature : fixed installation: -5°C to +70°C
